Igo Outland Laurentian

Ready to roll over anything you point it at. Thanks to its comfortable yet sporty geometry and full suspension front fork, hours in the saddle feel like fleeting moments of exhilaration.

SPECIFICATIONS:

FRAME: Hydroformed 6061 Aluminum Alloy 29er frame with smooth welds. Rack mounts, internal cable routing, Electronic Access Port. Removable integrated battery with security lock.

COLOR: Matte Race Red & Burgundy

FORK: SUNTOUR XCM HLO DS 29er suspension, 100mm travel, lockout

SHIFTERS: SRAM X5 9-speed trigger shift

FRONT DERAILLEUR: NA

CHAINRINGS: 44T

CHAIN: KMC X9

REAR DERAILLEUR: SRAM X5 9-speed long cage

CASSETTE: SRAM 9-speed 11-34T

HANDLEBAR: Low-rise, 700mm, 28mm rise, 31.8mm dia.

GRIPS: VELO with lock ring (131mm)

STEM: Alloy 50mm with 6 degree rise, 31.8mm clamp dia.

SEATPOST: Alloy 31.6mm with quick release

SADDLE: SELLE ROYAL

BRAKE LEVERS: TEKTRO with Sensor Control Design and reach adjustment

BRAKE CALIPERS: TEKTRO hydraulic disc

ROTORS: 180mm

TIRES: Maxxis Asseghai 29 x 2.5”

RIMS: Alloy 29r

ELECTRIC TECHNOLOGY:
iGO CONNECT Mobile App (Android and iOS)
Customizable profile and performance settings with full diagnostic monitoring and alerts - Bluetooth connectivity

DISPLAY UNIT TFT Color Backlit, Main Power, Vibration Feedback Buttons, Diagnostic, Battery Status, Light Switch, Pedal Assist Level Selector, Walk Assist Control, Speedometer/Max Speed/Avg Speed, Odometer, Trip Timer

MOTOR: 500W geared rear hub drive, 48V (750W US)

TORQUE: up to 65Nm

CONTROLLER: 48V high power density sine wave, MOSFET based up to 70 Amp, Bluetooth

BATTERY TYPE: SAMSUNG integrated removable lithium battery with security lock

BATTERY VOLTAGE (V) 48V

BATTERY (AH) 14Ah

BATTERY CAPACITY (WH) 672Wh

RANGE 70km (45mi) *

POWER ASSIST: 5 Levels of power assisted pedaling ***

THROTTLE: Any time on demand thumb throttle (Removable)

SENSOR: Dual sided 36 pulse Torque Sensor

CLASS** Class2 / Class1 optional / Class3 capable where permitted
max speed 45km/h (28mph)**

BATTERY CHARGER 110/220V Smart charger, LED status, UL, 2A

ACCESSORIES (INCLUDED) Dropout Rack Mount Eyelets, Water Bottle Boss on Down Tube, Kickstand, Tool Kit, Battery Charger

BIKE WEIGHT 23.1kg (51.0lbs)
BATTERY WEIGHT 3.1kg (6.8lbs)
WEIGHT CAPACITY 114kg (250lbs)
